Deploy Stable Diffusion XL on AWS inferentia2 with Amazon SageMaker

Published on
12 min read
View Code

In this end-to-end tutorial, you will learn how to deploy and speed up Stable Diffusion XL inference using AWS Inferentia2 and optimum-neuron on Amazon SageMaker. Optimum Neuron is the interface between the Hugging Face Transformers & Diffusers library and AWS Accelerators including AWS Trainium and AWS Inferentia2.

You will learn how to:

  1. Convert Stable Diffusion XL to AWS Neuron (Inferentia2) with optimum-neuron
  2. Create a custom inference.py script for Stable Diffusion
  3. Upload the neuron model and inference script to Amazon S3
  4. Deploy a Real-time Inference Endpoint on Amazon SageMaker
  5. Generate images using the deployed model

Quick intro: AWS Inferentia 2

AWS inferentia (Inf2) are purpose-built EC2 for deep learning (DL) inference workloads. Inferentia 2 is the successor of AWS Inferentia, which promises to deliver up to 4x higher throughput and up to 10x lower latency.

instance sizeacceleratorsNeuron Coresaccelerator memoryvCPUCPU Memoryon-demand price ($/h)
inf2.xlarge12324160.76
inf2.8xlarge1232321281.97
inf2.24xlarge612192963846.49
inf2.48xlarge122438419276812.98

Additionally, inferentia 2 will support the writing of custom operators in c++ and new datatypes, including FP8 (cFP8).

Let's get started! 🚀

If you are going to use Sagemaker in a local environment (not SageMaker Studio or Notebook Instances). You need access to an IAM Role with the required permissions for Sagemaker. You can find here more about it.

1. Convert Stable Diffusion to AWS Neuron (Inferentia2) with optimum-neuron

We are going to use the optimum-neuron to compile/convert our model to neuronx. Optimum Neuron provides a set of tools enabling easy model loading, training and inference on single- and multi-Accelerator settings for different downstream tasks.

As a first step, we need to install the optimum-neuron and other required packages.

Tip: If you are using Amazon SageMaker Notebook Instances or Studio you can go with the conda_python3 conda kernel.

# Install the required packages
%pip install "optimum-neuron==0.0.13" "diffusers==0.21.4" --upgrade
%pip install "sagemaker>=2.197.0"  --upgrade

After we have installed the optimum-neuron we can convert load and convert our model.

We are going to use the stabilityai/stable-diffusion-xl-base-1.0 model. Stable Diffusion XL (SDXL) from Stability AI is the newset text-to-image generation model, which can create photorealistic images with detailed imagery and composition compared to previous SD models, including SD 2.1.

At the time of writing, the AWS Inferentia2 does not support dynamic shapes for inference, which means that the we need to specify our image size in advanced for compiling and inference.

In simpler terms, this means we need to define the input shapes for our prompt (sequence length), batch size, height and width of the image.

We precompiled the model with the following parameters and pushed it to the Hugging Face Hub:

  • height: 1024
  • width: 1024
  • num_images_per_prompt: 1
  • batch_size: 1
  • neuron: 2.15.0

Note: If you want to compile your own model or a different Stable Diffusion XL checkpoint you need to use ~120GB of memory and the compilation can take ~45 minutes. We used an inf2.8xlarge ec2 instance with the Hugging Face Neuron Deep Learning AMI to compile the model.

from huggingface_hub import snapshot_download

# compiled model id
compiled_model_id = "aws-neuron/stable-diffusion-xl-base-1-0-1024x1024"

# save compiled model to local directory
save_directory = "sdxl_neuron"
# Downloads our compiled model from the HuggingFace Hub
# using the revision as neuron version reference
# and makes sure we exlcude the symlink files and "hidden" files, like .DS_Store, .gitignore, etc.
snapshot_download(compiled_model_id, revision="2.15.0", local_dir=save_directory, local_dir_use_symlinks=False, allow_patterns=["[!.]*.*"])


###############################################
# COMMENT IN BELOW TO COMPILE DIFFERENT MODEL #
###############################################
#
# from optimum.neuron import NeuronStableDiffusionXLPipeline
#
# # model id you want to compile
# vanilla_model_id = "stabilityai/stable-diffusion-xl-base-1.0"
#
# # configs for compiling model
# compiler_args = {"auto_cast": "all", "auto_cast_type": "bf16"}
# input_shapes = {
#   "height": 1024, # width of the image
#   "width": 1024, # height of the image
#   "num_images_per_prompt": 1, # number of images to generate per prompt
#   "batch_size": 1 # batch size for the model
#   }
#
# sd = NeuronStableDiffusionXLPipeline.from_pretrained(vanilla_model_id, export=True, **input_shapes, **compiler_args)
#
# # Save locally or upload to the HuggingFace Hub
# save_directory = "sdxl_neuron"
# sd.save_pretrained(save_directory)

2. Create a custom inference.py script for Stable Diffusion

The Hugging Face Inference Toolkit supports zero-code deployments on top of the pipeline feature from 🤗 Transformers. This allows users to deploy Hugging Face transformers without an inference script [Example].

Currently is this feature not supported with AWS Inferentia2, which means we need to provide an inference.py for running inference. But optimum-neuron has integrated support for the 🤗 Diffusers pipeline feature. That way we can use the optimum-neuron to create a pipeline for our model.

If you want to know more about the inference.py script check out this example. It explains amongst other things what the model_fn and predict_fn are.

# create code directory in our model directory
!mkdir {save_directory}/code

We are using the NEURON_RT_NUM_CORES=2 to make sure that each HTTP worker uses 2 Neuron core to maximize throughput.

%%writefile {save_directory}/code/inference.py
import os
# To use two neuron core per worker
os.environ["NEURON_RT_NUM_CORES"] = "2"
import torch
import torch_neuronx
import base64
from io import BytesIO
from optimum.neuron import NeuronStableDiffusionXLPipeline


def model_fn(model_dir):
    # load local converted model into pipeline
    pipeline = NeuronStableDiffusionXLPipeline.from_pretrained(model_dir, device_ids=[0, 1])
    return pipeline


def predict_fn(data, pipeline):
    # extract prompt from data
    prompt = data.pop("inputs", data)

    parameters = data.pop("parameters", None)

    if parameters is not None:
        generated_images = pipeline(prompt, **parameters)["images"]
    else:
        generated_images = pipeline(prompt)["images"]

    # postprocess convert image into base64 string
    encoded_images = []
    for image in generated_images:
        buffered = BytesIO()
        image.save(buffered, format="JPEG")
        encoded_images.append(base64.b64encode(buffered.getvalue()).decode())

    # always return the first
    return {"generated_images": encoded_images}

3. Upload the neuron model and inference script to Amazon S3

Before we can deploy our neuron model to Amazon SageMaker we need to upload it all our model artifacts to Amazon S3.

Note: Currently inf2 instances are only available in the us-east-2 & us-east-1 region [REF]. Therefore we need to force the region to us-east-2.

Lets create our SageMaker session and upload our model to Amazon S3.

import sagemaker
import boto3
sess = sagemaker.Session()
# sagemaker session bucket -> used for uploading data, models and logs
# sagemaker will automatically create this bucket if it not exists
sagemaker_session_bucket=None
if sagemaker_session_bucket is None and sess is not None:
    # set to default bucket if a bucket name is not given
    sagemaker_session_bucket = sess.default_bucket()

try:
    role = sagemaker.get_execution_role()
except ValueError:
    iam = boto3.client('iam')
    role = iam.get_role(RoleName='sagemaker_execution_role')['Role']['Arn']

sess = sagemaker.Session(default_bucket=sagemaker_session_bucket)

print(f"sagemaker role arn: {role}")
print(f"sagemaker bucket: {sess.default_bucket()}")
print(f"sagemaker session region: {sess.boto_region_name}")
assert sess.boto_region_name in ["us-east-2", "us-east-1"] , "region must be us-east-2 or us-west-2, due to instance availability"

We create our model.tar.gz with our `inference.py`` script

# create a model.tar.gz archive with all the model artifacts and the inference.py script.
%cd {save_directory}
!tar zcvf model.tar.gz *
%cd ..

Next, we upload our model.tar.gz to Amazon S3 using our session bucket and sagemaker sdk.

from sagemaker.s3 import S3Uploader

# create s3 uri
s3_model_path = f"s3://{sess.default_bucket()}/neuronx/sdxl"

# upload model.tar.gz
s3_model_uri = S3Uploader.upload(local_path=f"{save_directory}/model.tar.gz", desired_s3_uri=s3_model_path)
print(f"model artifcats uploaded to {s3_model_uri}")

4. Deploy a Real-time Inference Endpoint on Amazon SageMaker

After we have uploaded our model artifacts to Amazon S3 can we create a custom HuggingfaceModel. This class will be used to create and deploy our real-time inference endpoint on Amazon SageMaker.

The inf2.xlarge instance type is the smallest instance type with AWS Inferentia2 support. It comes with 1 Inferentia2 chip with 2 Neuron Cores. This means we can use 2 Neuron Cores to minimize latency for our image generation.

from sagemaker.huggingface.model import HuggingFaceModel

# create Hugging Face Model Class
huggingface_model = HuggingFaceModel(
   model_data=s3_model_uri,        # path to your model.tar.gz on s3
   role=role,                      # iam role with permissions to create an Endpoint
   transformers_version="4.34.1",  # transformers version used
   pytorch_version="1.13.1",       # pytorch version used
   py_version='py310',             # python version used
   model_server_workers=1,         # number of workers for the model server
)

# deploy the endpoint endpoint
predictor = huggingface_model.deploy(
    initial_instance_count=1,      # number of instances
    instance_type="ml.inf2.xlarge", # AWS Inferentia Instance
    volume_size = 100
)
# ignore the "Your model is not compiled. Please compile your model before using Inferentia." warning, we already compiled our model.

5. Generate images using the deployed model

The .deploy() returns an HuggingFacePredictor object which can be used to request inference. Our endpoint expects a json with at least inputs key. The inputs key is the input prompt for the model, which will be used to generate the image. Additionally, we can provide inference parameters, e.g. num_inference_steps.

The predictor.predict() function returns a json with the generated_images key. The generated_images key contains the 1 generated image as a base64 encoded string. To decode our response we added a small helper function decode_base64_to_image which takes the base64 encoded string and returns a PIL.Image object and display_image displays them.

from PIL import Image
from io import BytesIO
from IPython.display import display
import base64

# helper decoder
def decode_base64_image(image_string):
  base64_image = base64.b64decode(image_string)
  buffer = BytesIO(base64_image)
  return Image.open(buffer)

# display PIL images as grid
def display_image(image=None,width=500,height=500):
    img = image.resize((width, height))
    display(img)

Now, lets generate some images. As example A dog trying catch a flying pizza in style of comic book, at a street corner.. Generating an image with 25 steps takes around ~6 seconds, except for the first request which can take 45-60s. note: If the request times out, just rerun again. Only the first request takes a long time.

prompt = "A dog trying catch a flying pizza at a street corner, comic book, well lit, night time"

# run prediction
response = predictor.predict(data={
  "inputs": prompt,
  "parameters": {
    "num_inference_steps" : 25,
    "negative_prompt" : "disfigured, ugly, deformed"
    }
  }
)

# decode and display image
display_image(decode_base64_image(response["generated_images"][0]))
results

Delete model and endpoint

To clean up, we can delete the model and endpoint.

predictor.delete_model()
predictor.delete_endpoint()

Conclusion

In this post, we deployed Stable Diffusion XL on a single inf2.xlarge instance costing $0.99/hour on Amazon SageMaker using Optimum Neuron. We achieved ~6s per image generation leading to ~10 images per minute or ~600 images per hour. This would translate to ~0.0016$ per image if utilized well. For startups and companies looking into GPU alternative Inferentia2 is a great option for not only efficient and fast but also cost-effective inference.


Thanks for reading! If you have any questions, feel free to contact me on Twitter or LinkedIn.
